| Motor features | |
| Load Capacity | 3200 kg en D8 / 2500 kg en D8+ |
| Lifting speed | 4 m/min ou 8m/min |
| FEM class | 1Bm |
| Insulation class | F |
| Noise level in operation | 75dB à 1 mètre |
| Motor HP | 1.50 kW |
| Chain specifications | |
| Chain dimensions | 11.75 x 32.9 mm |
| Approx. chain weight | 3,53 kg par mètre |
| Electrical features of the hoist | |
| Power consumption (full load) | 6.1 A |
| Physical characteristics | |
| Weight | 71 kg en version D8+ / 74 kg en version D8 |
| IP class | IP65 |
| Hook specifications | |
| Hook opening | 32 mm |
