| Physical characteristics | |
| Height | 194 mm |
| Width | 321 mm |
| Depth | 582 mm |
| Weight | 57 kg |
| IP class | IP66 |
| Motor features | |
| Load Capacity | 1000 kg |
| FEM class | 2M |
| Noise level in operation | 68 db |
| Duty factor | 40% |
| Motor HP | 1 HP |
| Chain specifications | |
| Chain dimensions | 7.9 x 21.7 |
| Approx. chain weight | 1.65 per meter |
| Electrical features of the hoist | |
| Power consumption (full load) | 2.3A |
| Operating voltage | 400-3-50 |
