The GigaCore O26-I is a 40 Gigabit Ethernet switch designed for AV integration, fixed installations, and touring. It supports the most advanced AV protocols right out of the box.
It is an ideal solution as a high-speed network core for professional AV infrastructures in star or mesh topologies.
Bandwidth, connectivity, and port count are no longer a limitation thanks to:
20 independent SFP+ ports up to 10 Gbps
4 SFP28 ports up to 25 Gbps
2 QSFP ports up to 40 Gbps
The GigaCore O26-I is designed for AV networks requiring:
high bandwidth,
high reliability,
quick and easy deployment.
It also integrates two redundant power supplies into a single 1U rack space.
| DMX features | |
| Supported Protocols | Dante©, RAVENNA/AES67©, Ethersound©, Q-LAN, REAC©, sACN, ArtNet, MANet2, HogNet, RTTrPL (BlackTraX), IEEE 802.1p CoS (Class of Service), DiffServ (DSCP), PoE (802.3af) (optional), PoE+ (optional), IEEE 1588 PTP V2 |
| Physical characteristics | |
| Height | 44mm |
| Width | 482 mm |
| Depth | 204,3 mm |
| Weight | 2,9 kg |
| Enclosure | Bended metal |
| Operating Temperature | 0 à +50 °C |
| Ethernet features | |
| PoE | LED de statut |
| RLinkX | LED de statut |
| Conformité Ethernet | IEEE 802.3, IEEE 802.3u, IEEE 802.3x Flow Control, IEEE 802.3ab Gigabit Ethernet |
| Ports features | |
| Vitesse des ports | 1000 Mbps |
| Détection des ports | Auto negotiation (10BaseT, 100BaseTx, 1000BaseT) Full or Half Duplex |
| Network features | |
| Redondance | RLinkX |
| Segmentation VLAN | Groupes |
| Link aggregation | MultiLinkX |
| IGMP snooping | Oui |
| IGMP | (V1/V2/V3) |
| Profile manager | Yes |
| Capacité de commutation | 32Gbps |
| Croisement automatique | MDI / MDIX (câble droit ou croisé) |
| Connectivity | |
| Ethernet Ports | 12 |
| Fiber Ports | 2 |
| Connector Type | RJ45 et cages SFP |
| Power | |
| Consumption | 30W maximum (180W avec option PoE) |
| Fuse | Fusible temporisé 3.15A 250V |
| Alimentation | Status LED |
| Power Input | 100-240VAC, 50-60Hz |
| Power | 1 x IEC avec porte fusible + 1 x entrée redondante en connecteur Molex Mini-fit Junior 6 broches + 1x entrée redondante PoE en connecteur Molex Mini-fit Junior 6 broches |
| Backup power input | 15VDC / 2A |
| Backup PoE power input | 48VDC / 3.4A |
| Environment | |
| Humidity | 5-95% non-condensing |
| Storage Temperature | -10 à +70 °C |
| Approvals | |
| Standards | EN 60950-1, EN 55022, EN 55024 |
| Approvals | CE |
| Additional features | |
| Mémoire | 4Mb |
